IoTLINK Pack

Wireless Multi-Functional IoT Tracker/Transmitter

IoTLink Pack is a battery-powered self-contained device, offering both Track and Monitoring
applications. IoTLink Pack is capable of reporting directly to a cloud server or via cellular gateway
such as ERM's StarLINK family of telematics devices.
It is designed to use very low power consumption to maintain the longest as possible operation
period.

IoTLink Pack offers immediate and wireless implementation in any application without the need of wiring or an external power source of any kind.
IoTLink Pack is a great solution for visible or concealed tracking.
Using ERM’s special power management technology, IoTLink Pack will transmit its location and additional alerts for long period of time without the need to recharge.

1

Cloud connectivity via Cellular communication

Vicinity connectivity via Standard Short-Range communication

No installation required

Remote configuration and management (FOTA)

Rechargeable battery

Command-controlled transmission profiling for power endurance

Cellular

4G LTE CATm-1 / NB-IoT with optimized embedded antenna

Location

GPS/GLONASS/GALILEO, Active antenna, Sensitivity -165 dB, NMEA,
Acquisition (normal): cold <34s, warm <30s, hot <1s, accuracy: 2.5m CEP
Embedded optimized antenna

Communication

Text messages, TCP/IP over GPRS/UMTS/EDGE/HSPA,
Standard short range communication module v4.0, 2.4GHz (in RF Variant)

Power Supply

Internal rechargeable battery 3.6VDC, 4,400mA

Configuration /
Firmware Update

OTA, parameters setup, software programming

Data Logger

Up to 1,000 messages

1

Track and Trace

Driver Identification

Predictive maintenance

Cargo Safety

Vehicle Security and SVR/SVT

Insurance (UBI)

Toll Collection

Driver Assistance and Safety

Micro Mobility Vehicles Battery Monitoring (up to 80vDC)

Mining and Yellow Machinary

Advanced Vehicle Analysis

Motorbike Tracking and Security

Asset Tracking and Monitoing

Self Powered Assets and Delivery tracking

Cellular Gateway for IoT Tags/Sensors

Wifi Gateway for IoT Tags/Sensors

Cement Mixing Trucks Monitoring

Tracking

Purpose: Regular tracking
Explanation: The device will be used as a tracker, continuously transmitting its location and other parameters in pre-defined time intervals.

Idle

Purpose: Power conservation is important, and the system only wants to know that the device is alive
Explanation: The device transmits its location in pre-defined time intervals. A set of conditions can be configured to automatically change mode to Tracking or manually by a command sent from the server.

Moving / Stop

Explanation: The device will transmit its location and configured parameters every time it starts moving and when it stops moving.

Auto Tracking

Explanation: The device will automatically switch modes between Idle to Tracking based on pre-defined conditions.

Manual

Purpose: When power conservation is critical
Explanation: The device will transmit location and pre-defined parameters for a pre-defined period of time and time intervals.
